Koudgewalste of Warmgewalste Dikte van de Roestvrij staalplaat 6 - 80mm Q235 Q345 B C D E
Product Details
| Productnaam: | de plaat van het legeringsstaal | Norm: | AISI, ASTM, BS, DIN, JIS |
|---|---|---|---|
| Toepassing: | Schipplaat | Techniek: | koudgewalst/Warmgewalst |
| Markeren |
drukvatplaat,De Plaat van het schipstaal |
||
Product Description
Q235 Q345 B C D E walsten/warmgewalste de plaatdikte van het legeringsstaal 6 - 80mm koud
Q345B/C/D/E
1)Norm: GB
2)Dikte: 680mm
3)Breedte: 16003200mm
4)Lengte: 600014000mm
5))Hoog - kwaliteits lage prijs
Chemische Constituent (% gew.)
| C | Si | Mn | P | S | V | Nb | Al | Ti | |
| Q345A | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.045 | ≤0.045 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345B | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.040 | ≤0.040 | 0.02-0.15 | 0.015-0.060 | - | 0.02-0.20 |
| Q345C | ≤0.20 | ≤0.55 | 1.00-1.60 | ≤0.035 | ≤0.035 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345D | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.030 | ≤0.030 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
| Q345E | ≤0.18 | ≤0.55 | 1.00-1.60 | ≤0.025 | ≤0.025 | 0.02-0.15 | 0.015-0.060 | ≥0.015 | 0.02-0.20 |
Mechanische Properities
| dikte | testtemperatuur (°c) | Verlenging (%) | bewijsspanning (Mpa) | Trekstrenth (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
Onze producten
| Productreeks | Uitvoerende Norm | Rang | Klasse | Dikte (mm) |
Levering Staat |
| Low-alloy structureel staal | GB/T 1591-2008GB/T 3274-2007 | Q345 | A, B | 6~150 | AR |
| C, D | 6~150 | Cr | |||
| E | 6~150 | TMCP | |||
| Q390 | A, B, C, D, E | 6~150 | Cr | ||
| Q420 | 6~150 | TMCP | |||
| Q500 | 6~100 | TMCP | |||
| Q550 | 6~100 | ||||
| Q620 | 6~80 | ||||
| Q690 | 6~80 | ||||
| GB/T 28410-2012 | Q235FT | B, C, D, E | 5~150 | AR, CR | |
| Q275FT | C, D, E, F | 5~150 | AR, CR | ||
| Q345FT | C, D, E, F | 5~150 | AR, CR | ||
| Q420FT | C, D, E, F | 5~150 | AR, CR | ||
| Q460FT | C, D, E, F | 5~150 | AR, CR | ||
| ENGELS 10025-4:2004 | S275M/ML | - | 6~60 | TMCP | |
| S355M/ML | |||||
| S420M/ML | |||||
| S460M/ML | |||||
| JIS G3106: 2008 |
SM400 SM490 |
A, B, C | 6~150 | AR | |
| A, B, C | 6~150 | Cr | |||
| YA, YB | |||||
| SM520 | B, C | 6~80 | TMCP | ||
| SM570 | 6~80 | ||||
| ASTM A572/A572M-12 | Gr42 | - | 6~150 | AR | |
| Gr50 | - | 6~100 | Cr | ||
| Gr55 | - | 6~100 | |||
| Gr60 | - | 6~80 |
TMCP |
Product Highlights
Q235 Q345 B C D E walsten/warmgewalste de plaatdikte van het legeringsstaal 6 - 80mm koud Q345B/C/D/E 1)Norm: GB 2)Dikte: 680mm 3)Breedte: 16003200mm 4)Lengte: 600014000mm 5))Hoog - kwaliteits lage prijs Chemische Constituent (% gew.) C Si Mn P S V Nb Al Ti Q345A ≤0.20 ≤0.55 1.00-1.60 ≤0.045 ≤0.045 ...
