DIN17175 Buis 4 van het boilerstaal de corrosieweerstand van de Ribbendraad
Product Details
| Productnaam: | Buis van de Koolstofstaal de Naadloze Boiler | Toepassing: | Voor hoge, midden, lage drukboiler en drukdoel |
|---|---|---|---|
| Norm: | DIN17175 | Materiaal: | ST35.8 |
| Markeren |
DIN17175 de Buis van het boilerstaal,de Buis van het de Boilerstaal van de 4 ribbendraad,DIN17175 ingepaste draadbuis |
||
Product Description
Van de de Boilerbuis van het hoge druk Naadloze Koolstofstaal St 37,8 Koolstofstaalpijp
Productienorm: GB/T20409-2006
SteelGrade: 20G, 20MNG, 25MNG, 12CRMOG, 15CRMOG, SA210A1, SA210C, SA213T2/T12, WB36, T91, T11,
P11, P22, P92, P5, P9, R102, CR5MO, 16MO3,12CR2MOWVTIB
Past Aantal in: 4ribs/6ribs/8ribs/12ribs
De interne de boiler Rifled buis van de Draadhoge druk is één soort endophragmprocessen de spiraalvormige lijn de naadloze staalpijp. Hoofdtoepassing binnen op de waterkoelingsmuur van de boiler van het capaciteitsnut. Gewoonlijk met de fluorescente buis die gebruikt vergelijkt, kan het de kernebullition voorwaarde onder de hoge exploitatievoorwaarde van de koortslading handhaven, vermijdt dus verzendend ebullition van de filmvoorwaarde, verhindert de pijp zich uit te branden, verlengt de pijplevensduur.
Chemical&Mechanicalparameters
| Rang | C | Mn | Si | Cr | Mo | S | P |
| 20G | 0.17~0.23 | 0.35~0.65 | 0.17~0.37 | - | - | ≤0.020 | ≤0.025 |
| 20MnG | 0.17~0.23 | 0.70~1.00 | 0.17~0.37 | - | - | ≤0.020 | ≤0.025 |
| 25MnG | 0.22~0.29 | 0.70~1.00 | 0.17~0.37 | - | - | ≤0.020 | ≤0.025 |
| 12CrMoG | 0.08~0.15 | 0.40~0.70 | 0.17~0.37 | 0.40~0.70 | 0.40~0.55 | ≤0.020 | ≤0.025 |
| 15CrMoG | 0.12~0.18 | 0.40~0.70 | 0.17~0.37 | 0.80~1.10 | 0.40~0.55 | ≤0.020 | ≤0.025 |
| Sa-210A1 | ≤0.27 | ≤0.93 | ≥0.10 | - | - | ≤0.035 | ≤0.035 |
| Sa-210C | ≤0.35 | 0.29~1.06 | ≥0.10 | - | - | ≤0.035 | ≤0.035 |
| Sa-213T2 | 0.10~0.20 | 0.30~0.61 | 0.10~0.30 | 0.50~0.81 | 0.44~0.65 | ≤0.025 | ≤0.025 |
| Sa-213T12 | 0.05~0.15 | 0.30~0.61 | ≤0.50 | 0.80~1.25 | 0.44~0.65 | ≤0.025 | ≤0.025 |
| Rang | T (MPa) | Y (MPa) | E (%) | Hardheid |
| 20G | 410~550 | 245 | ≥24 | - |
| 20MnG | ≥415 | ≥240 | ≥22 | - |
| 25MnG | ≥485 | ≥275 | ≥20 | - |
| 12CrMoG | 410~560 | ≥205 | ≥21 | - |
| 15CrMoG | 440~640 | ≥235 | ≥21 | - |
| Sa-210C | ≥415 | ≥255 | ≥30 | ≤143HBW |
| Sa-210A1 | ≥485 | ≥275 | ≥30 | ≤179HBW |
| Sa-213T2 | ≥415 | ≥205 | ≥30 | ≤163HBW |
| Sa-213T12 | ≥415 | ≥220 | ≥30 | ≤163HBW |
| Buisgrootte voor Warmtewisselaars & Condensatoren & Boiler | |||||||||||
| Buitendiameter | BWG | ||||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||||
| Muurdikte mm | |||||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||||
| mm | duim | Gewicht kg/m | |||||||||
| 6.35 | 1/4 | 0,081 | 0,109 | 0,133 | 0,174 | 0,212 | |||||
| 9.53 | 3/8 | 0,126 | 0,157 | 0,193 | 0,257 | 0,356 | 0,429 | ||||
| 12.7 | 1/2 | 0,214 | 0,263 | 0,356 | 0,457 | 0,612 | 0,754 | ||||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0,995 | ||||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1,236 | ||||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1,234 | 1,574 | 2.05 | |||
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1,244 | 1,574 | 2,014 | 2,641 | |||
| 38.1 | 1 1/2 | 0,667 | 0,832 | 1,144 | 1,514 | 1,904 | 2,454 | 3,233 | |||
| 44.5 | 1 3/4 | 1,342 | 1,774 | 2,244 | 2,894 | 3.5 | |||||
| 50.8 | 2 | 1,549 | 2,034 | 2,574 | 3,334 | 4.03 | |||||
| 63.5 | 2 1/2 | 1,949 | 2,554 | 3,244 | 4,214 | 5.13 | |||||
| 76.2 | 3 | 2,345 | 3,084 | 3,914 | 5,094 | 6.19 | |||||
| 88.9 | 3 1/2 | 2,729 | 3,609 | 4,584 | 5,974 | 7.27 | |||||
| 101.6 | 4 | 4,134 | 5,254 | 6,854 | 8.35 | ||||||
| 114.3 | 4 1/2 | 4,654 | 5,924 | 7,734 | 9.43 | ||||||
| Vorm van Buis: Rechtstreeks & U-bocht & Finned & Gerold | |||||||||||
| Roestvrij staalbuis: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81. | |||||||||||
| Buis van het koolstof de &Alloy Staal: A/SA178, A/SA179, A/SA192, A/SA209, A/SA210, A/SA213, A.SA214 |
|||||||||||
