De Gelaste Opgepoetste Pijp van TP 304 316L 321 904L Ss
Product Details
| Materiaal: | TP304 TP304L TP316 TP316L, 300 Reeksen | Het eindigen: | Onthard & Ingelegde oplossing |
|---|---|---|---|
| Toepassing: | boiler&heat ruilmiddel, energie, petrochemische stof, mijnbouw, voedsel, document, gas en de vloeiba | Vorm: | Gelaste buis |
| OD: | 15.9mm tot 406.4mm | gewicht: | 0.89mm tot 5mm |
| Markeren |
904L Ss Gelaste Pijp,321 Ss Gelaste Pijp,De Gelaste Pijp van TP 304 Ss |
||
Product Description
Ss van TP 304 316L 321 310S 904L het Roestvrije staal laste Opgepoetste Pijp/Buis
Productparameter
| Grootte OD | Nominale Muur | Buitendiameter | Lengte | Muur |
| 1/2“ (12,7) | 0,065“ (1,65)/0,049“ (1,25) | +/0,005 (0,13) | +1/8“ (3,18) - 0 | +/10,0% |
| 3/4“ (19,1) | 0,065“ (1,65)/0,049“ (1,25) | +/0,005 (0,13) | +1/8“ (3,18) - 0 | +/10,0% |
| 1“ (25,4) | 0,065“ (1,65)/0,049“ (1,25) | +/0,005 (0,13) | +1/8“ (3,18) - 0 | +/10,0% |
| 11/2“ (38,1) | 0,065“ (1,65)/0,049“ (1,25) | +/0,008“ (0,20) | +1/8“ (3,18) - 0 | +/10,0% |
| 2“ (50,8) | 0,065“ (1,65)/0,049“ (1,25) | +/0,008“ (0,20) | +1/8“ (3,18) - 0 | +/10,0% |
| 21/2“ (63,5) | 0,065“ (1,65) | +/0,010“ (0,25) | +1/8“ (3,18) - 0 | +/10,0% |
| 3“ (76,2) | 0,065“ (1,65) | +/0,010“ (0,25) | +1/8“ (3,18) - 0 | +/10,0% |
| 4“ (101,6) | 0,083“ (2,11) | +/0,015“ (0,38) | +1/8“ (3,18) - 0 | +/10,0% |
| 6“ (152,4) | 0,083“ (2,11) | +/0,030“ (0,76) | +1“ (25,4) - 0 | +/10,0% |
| 6“ (152,4) | 0,109“ (2,77) | +/0,030“ (0,76) | +1“ (25,4) - 0 | +/10,0% |
| 8“ (203,2) | 0,109“ (2,77) | +0.061“ (1,55) /0,031“ (0,79) | +1“ (25,4) - 0 | +/10,0% |
Toepassing:
a) Voor vloeistof en gasvervoer
b) Structuur en het machinaal bewerken
c) Warmtewisselaarpijpen enz.
Voordelen:
a) De superieure oppervlakte eindigt
b) Beter mechanisch bezit
c) Nauwkeurigere afmeting
d) Perfecte inspectiemethode en inspectiemateriaal
| Termijnen & Voorwaarden | Prijspunt | FOB, CFR, CIF of als onderhandeling |
| Betaling | T/T, LC of als onderhandeling | |
| Levertijd | 30 ontvingen de werkdagen na uw storting (normaal volgens de ordehoeveelheid) | |
| Pakket | Ijzergeval; geweven zak of vanaf de eis van de klant | |
| Kwaliteitsvereiste | Het Certificaat van de molentest zal van verzending worden voorzien, is de Derde Deelinspectie aanvaardbaar | |
| Kwaliteit | Test | Röntgenstraal, Groottetest, Lengtetest |
| Chemische Analyse (Foto-elektrische Spectroscopische Emissie) enz. | ||
| Markt | Hoofdmarkt | Europa, Midden-Oosten, Zuidoost-Azië, Zuid-Amerika. Enz. |
